AGP Gold Foil Stamping Solution UV DTF Foil Stamping Sticker Printer
AGP UV-S604 printer self-developed uv dtf printer(crystal label printer), small footprint, easy to use and easy to operate, it is one of the first choice for DIY small shop business. It supports CMYK+W+Varnish. The speed can reach to 10㎡/h. It can print gold/silver foil stamping solution, which is very beautiful and attractive.
AGP UV-S604 printer self-developed uv dtf printer(crystal label printer), small footprint, easy to use and easy to operate, it is one of the first choice for DIY small shop business. It supports CMYK+W+Varnish. The speed can reach to 10㎡/h. It can print gold/silver foil stamping solution, which is very beautiful and attractive.
The steps of gold/silver foil stamping solution:
CMYK+W+V1+V2
V1=Normal Varnish
V2=Special Varnish
Step 1: Printing on Film A
Step 2: Laminating waste discharge film and remove the laminated dischgarge film
Step 3: Laminating Golden/Silver film and remove extra Golden/Silver foil (Using a seperate laminator)
Step 4: Laminating Transfer Film (Using a seperate laminator)
Parameter of UV-S604 printer
| Model | UV-S604 | ||
| Printhead | Epson I3200-U1/Epson I1600-U1 | ||
| Quantity | 3 | 4 | |
| Printing Color | W+CMYK+V | G+W+CMYK+V | |
| Printing Speed | I3200-U1 | 6PASS 3-10m²/h 8PASS 2.5-8m²/h 12PASS2-6m²/h | |
| 11600-U1 | 4PASS 4m²/h 6PASS 3m²/h 8PASS 2m²/h | ||
| Printing Size | 600mm | ||
| RIP Software | Riin/Flexiprint/Cadlink/Maintop | ||
| Print Media | UV AB Film | ||
| Laminator | Integrated automatic laminator | ||
| Ink supply system | White ink circulation and stirring | ||
| Ink curing | Water cooler+UVLED lamp (to ensure long-term high-intensity operation) | ||
| Power Supply | 110V/220V 50-60HZ | ||
| Sleeping:45W
Standby:1100W Working:2000W |
|||
| Work Environment | Temperature:20°C-30°C humidity:35%-65% | ||
| Dimension | 1800*870*1600mm | ||
