AGP printer source manufacturer uv 3040 printer can be used to print leather, acrylic and mobile phone cases
Observation mirror design
The mirror design at the bottom of the trolley cabin allows you to observe the surface contamination of the nozzle and bottom plate without blind spots, and maintain the nozzle intuitively and effectively.
Double-head lifting ink stack
Double-head automatic lifting ink stack, fully manufactured with CNC precision machining, ink absorption and scraping are accurate and effective.
Why choose us？
1. Anti-warping material
The anti-warping sheet can effectively prevent the edges of various materials from curling up and scratching the nozzle during printing.
2. Multifunctional air suction platform
The platform has special 2mm air suction holes and built-in segmented negative pressure chambers. The wind power is adjustable and can effectively absorb 60g-600g of materials of different thicknesses and qualities to ensure that the materials absorb ink effectively, fully and evenly in areas with different temperature differences.
3. Observation mirror design
The mirror design at the bottom of the trolley cabin allows you to observe the surface contamination of the nozzle and bottom plate without blind spots, and maintain the nozzle intuitively and effectively.
4. Double-head lifting ink stack
Double-head automatic lifting ink stack, fully manufactured with CNC precision machining, ink absorption and scraping are accurate and effective.
| Model | UV3040 |
| Printhead | Epson l3200-U1 HD Printhead |
| Printhead Quantity | 1 |
| Print Speed | 0.28m²/h~3m²/h |
| Print Width | Platform:297*420mm Cylinder:230*420mm |
| Print Media Thickness | 1mm~90mm |
| lnk Type | Environmental friendly UV curing ink |
| Color Configuration | Standard: CMYK+W+V Optional: YMCK LC LM+W |
| RIP Software | Maintop, FlexiPRINT,RIIN |
| Print Media | Glass, plates, various signs, crystal, PVC, acrylic, leather plastic, etc. |
| Photo Format | TIFF, JPEG, PDF, EPS, PNG, Al, BMP, etc. |
| Computer Configuration | Win10/64-bit system |
| Transmission Interface | Gigabit network port, hard disk 500G above |
| Rated Voltage/Power | 220V,50HZ/60HZ |
| Sleeping:30W
Working:500W |
|
| Work Environment | T:15°C~28°C, H: 40%~60%RH |
| Machine Size/Weight | 825mm*1019mm*612mm(L*W*H) 80KG |
