Manufacturer fully automatic PVC PET sheet cutting machine heavy duty cutting machine non-woven paper cross cutting machine
The C7090 cutting machine is usually used with our 60cm DTF printer, which can cut the DTF film after printing. After cutting, it can be transferred, which is very suitable for personalized heat transfer clothing customization.
Contact US
Get Price
Share:
Content
The C7090 cutting machine is usually used with our 60cm DTF printer, which can cut the DTF film after printing. After cutting, it can be transferred, which is very suitable for personalized heat transfer clothing customization.
| Model | C7090 |
| Max cutting speed | 1000mm/s |
| Cutting thickness | ≤1.2mm |
| Cutting material | Crystal labels / DTF pet film / self-adhesive Vinyl, etc |
| Cutting pressure | 1000g |
| Cutting method | Half cutting / Full cutting |
| Pen/Blade type | Double blade structure |
| Media hold method | Vacuum suction |
| Drive method | High-speed servo drive |
| Mechanical resolution | ±0.005mm |
| Standard Interface | USB / U disk /Ethernet (WIFI Optional) |
| Compatible software | Signmaster / Coreldraw / AI /AUTO CAD |
| Screen size | 6.0 inches touch screen |
| Power supply | Rated Voltage:220V
50/60Hz(auto switching) |
| Working:2200W | |
| Cutting area | 700*900mm,unlimited cutting length( auto section pulling materials) |
| Machine size/weight | 1460*1300*1000mm 220kg |
| Package size/weight | 1600*1300*1100mm 240kg |
What Can We Do with DTF Printers
Creativity At Your Fingertips
DTF printers can print on light and black fabrics, are not limited by fabrics and colors, especially suitable for DIY printing. Suitable for leather, bags, shoes, hats, garments, socks, masks, gloves, umbrellas, plush toys, knitted underwear, swimwear and other textile and textile crafts.
