Manufacturer fully automatic PVC PET sheet cutting machine heavy duty cutting machine non-woven paper cross cutting machine

The C7090 cutting machine is usually used with our 60cm DTF printer, which can cut the DTF film after printing. After cutting, it can be transferred, which is very suitable for personalized heat transfer clothing customization.

Rated 4.8/5 based on 512 customer reviews
Share:
Content

The C7090 cutting machine is usually used with our 60cm DTF printer, which can cut the DTF film after printing. After cutting, it can be transferred, which is very suitable for personalized heat transfer clothing customization.



Model C7090
Max cutting speed 1000mm/s
Cutting thickness ≤1.2mm
Cutting material Crystal labels / DTF pet film / self-adhesive Vinyl, etc
Cutting pressure 1000g
Cutting method Half cutting / Full cutting
Pen/Blade type Double blade structure
Media hold method Vacuum suction
Drive method High-speed servo drive
Mechanical resolution ±0.005mm
Standard Interface USB / U disk /Ethernet (WIFI Optional)
Compatible software Signmaster / Coreldraw / AI /AUTO CAD
Screen size 6.0 inches touch screen
Power supply Rated Voltage:220V

50/60Hz(auto switching)

Working:2200W
Cutting area 700*900mm,unlimited cutting length( auto section pulling materials)
Machine size/weight 1460*1300*1000mm 220kg
Package size/weight 1600*1300*1100mm 240kg

What Can We Do with DTF Printers
Creativity At Your Fingertips
DTF printers can print on light and black fabrics, are not limited by fabrics and colors, especially suitable for DIY printing. Suitable for leather, bags, shoes, hats, garments, socks, masks, gloves, umbrellas, plush toys, knitted underwear, swimwear and other textile and textile crafts.
