Unlocking the Mystery of UVF604: A Deep Dive into the 60 Crystal Stickers
Crystal label is also called UV transfer sticker, cultural sticker, UV cold transfer sticker, its predecessor is called sense pressure sticker, it is printed on special release material required graphics, printed on the A film with glue through the UV printer, after printing and then cover the transfer film B film, and then use the film to bring up the pattern transfer attached to the product surface of a surface graphic production process.
UV DTF printer can realize one piece of printing, no need to make a plate, that is, hit that out, that is, paste that tear, greatly eliminating a variety of tedious operating steps and processes, whether it is LOGO trademark or pattern, can be achieved, to meet the needs of many kinds of personalized small batch of custom customers.
| Model | UV-F604 |
| Printhead | 3*Epson i3200-U1/4*Epson 13200-U1 |
| Ink Channel | White + CMYK + Varnish |
| Printing Speed | 6PASS 3-10m²/h |
| 8PASS 2.5-8m²/h | |
| 12PASS 2-6m²/h | |
| Take-up & Feed-in System | Feed-in Film A, and take-up released protective film of film A |
| Feed-in laminating film B,and take-up finished film | |
| Print Width | Max 700mm |
| Lamination Function | Pneumatic intelligent adjustment of lamination balance,support hot lamination and cold lamination |
| Secondary Ink Cartridge Ink Supply System | To ensure a certain amount of ink in the secondary ink cartridge, siphon/negative pressure system |
| RIP Software | RIPrint/Photoprint/Printfactory |
| Image Format Support | TIFF/JPG/EPS/PDF/BMP etc. |
| Data Transmission | TCP/IP network interface |
| Printing Application | Mostly for crystal rub-on sticker, transfer decal film, crystal label sticker,PET film sticker |
| Machine Size/Weight | L/W/H: 195Omm*96Omm*16OOmm 180KG |
| Package Size | 2150mm*116Omm*1800mm |
1.Color ink cartridge, with air filter, ink outlet, liquid level sensor plug, double ink outlet.
2.Data control, software control or manual, data interface hardware facilities, double input and output guarantee.
3.Intelligent control adjustment, intelligent positioning system can also manually adjust front and rear, precise positioning, emergency stop button.
4.Intelligent display screen, accurate display of machine operation status and feedback, double platform lifting system.
