UV3040 A3 flat uv printer mobile phone case and bottle printing machine 3-in-1
AGP self-developed uv3040 printer, small footprint, easy to use, and easy to operate, with 1 head to accomplish white, color, and varnish printing at the same time. Support flat, cylinder and roll printing. Suitable for all kinds of personalized customization, it is one of the first choice for DIY small shop
Elevate your customization projects with the UV3040 printer, designed for precision, versatility, and vibrant color options. Tailored to handle a variety of surfaces—whether regular or irregular—this printer transforms the printing experience on materials like metal, leather, wood, paper, plastic, ceramic, glass, and more. Redefine the possibilities of UV printing with cutting-edge technology.
The UV3040 redefines printing with its versatile functionality, catering to various surfaces like metal, leather, wood, paper, plastic, ceramic, and glass. Featuring the Epson L3200-U1 HD Printhead, it ensures precise and clear prints on a 297x420mm platform and 230x420mm cylinder. With a standard CMYK+W+V color range and optional YMCK LC LM+W, this printer delivers vibrant hues, setting a new benchmark in UV printing technology.
| Model | UV3040 |
| Printhead | Epson l3200-U1 HD Printhead |
| Printhead Quantity | 1 |
| Print Speed | 0.28m²/h~3m²/h |
| Print Width | Platform:297*420mm Cylinder:230*420mm |
| Print Media Thickness | 1mm~90mm |
| lnk Type | Environmental friendly UV curing ink |
| Color Configuration | Standard: CMYK+W+V Optional: YMCK LC LM+W |
| RIP Software | Maintop, FlexiPRINT,RIIN |
| Print Media | Glass, plates, various signs, crystal, PVC, acrylic, leather plastic, etc. |
| Photo Format | TIFF, JPEG, PDF, EPS, PNG, Al, BMP, etc. |
| Computer Configuration | Win10/64-bit system |
| Transmission Interface | Gigabit network port, hard disk 500G above |
| Rated Voltage/Power | 220V,50HZ/60HZ |
| Sleeping:30W
Working:500W |
|
| Work Environment | T:15°C~28°C, H: 40%~60%RH |
| Machine Size/Weight | 825mm*1019mm*612mm(L*W*H) 80KG |
